Diameter |
M12 |
||
Flush Switching Distance | 2mm | 4mm | 6mm |
-Flush Switching Distance | 4mm | 8mm | 10mm |
Housing Material | Nickel plated brass | ||
With LED Without LED | |||
Max Load Current | 250mA | ||
Supply Voltage | 10-30 Volt DC | ||
Switching Frequency | 800Hz | ||
Response Time | 0.2ms/0.2ms | ||
Protecting category | IP67 | ||
Operating Temperature | -25ºC- +70ºC | ||
Short Circuit Protection | Yes | ||
Connecting Type | M12 Connector | ||
DC 3 wire 10-30V NPN N.O. | STI - M12NO- 2.5/4-C | ||
DC 3 wire 10-30V NPN N.C. | STI -M12NC- 2.5/4-C | ||
DC 3 wire 10-30V PNP N.O. | STI - M12PO- 2.5/4-C | ||
DC 3 wire 10-30V PNP N.C. | STI - M12PC- 2.5/4-C |
